Kyocera TASKalfa 6501i - Page 848

2N8/2N7
2-3-40
YC14
1 +3.3V O 3.3 V DC 3.3 V DC power to ODSW
Connected to
original
detection
switch
2 GND - - Ground
3 CO_SW I 0/3.3 V DC ODSW: On/Off
Connector Pin Signal I/O Voltage Description
