Kyocera TASKalfa 6501i - Page 876

2N8/2N7
2-3-68
YC8
20 GND - - Ground
Connected to
primary
paper feed
unit
21 CAS2_LIFT_UP_
SENS
I 0/3.3 V DC LS2: On/Off
22 5V O 5 V DC 5 V DC power to FS2
23 CAS2_P0_SENS I 0/3.3 V DC FS2: On/Off
24 GND - - Ground
YC10
1 ASIST_CL1 O 0/24 V DC ASCL1: On/Off
Connected to
assist clutch
1
2 24V2 O 24 V DC 24 V DC power to ASCL1
YC11
1 GND - - Ground
Connected to
feed PWB 1
2 GND - - Ground
3 GND - - Ground
4 +5V I 5 V DC 5 V DC power from FPWB1
5 +24V2 I 24 V DC 24 V DC power from FPWB1
6 +24V2 I 24 V DC 24 V DC power from FPWB1
YC12
1 ASIST_CL2 O 0/24 V DC ASCL2: On/Off
Connected to
assist clutch
2
2 24V2 O 24 V DC 24 V DC power to ASCL2
Connector Pin Signal I/O Voltage Description
