YC3 1 BRIDGE_SENS 1 O 0/5V DC BRCS1: On/Off
Connected to
the engine
PWB
2 BRIDGE OPEN O 0/5V DC BRCUSW: On/Off
3 BRIDGE_SENS 2 O 0/5V DC BRCS2: On/Off
4 BRIDGE1 DIR I 0/5V DC BRCM1 control signal
5 BRIDGE1 PD I 0/5V DC BRCM1 control signal
6 BRIDGE1 CLK I 0/5V DC(pulse) BRCM1 clock signal
7 BRIDGE1 MODE I 0/5V DC BRCM1 mode signal
8 BRIDGE1 REM I 0/5V DC BRCM1: On/Off
9 BRIDGE2 DIR I 0/5V DC BRCM2 control signal
10 BRIDGE2 PD I 0/5V DC BRCM2 control signal
11 BRIDGE2 CLK I 0/5V DC(pulse) BRCM2 clock signal
12 BRIDGE2 MODE I 0/5V DC BRCM2 mode signal
13 BRIDGE2 REM I 0/5V DC BRCM2: On/Off
YC4 1 GND - - Ground
Connected to
the BR con-
veying sen-
sor 2
2 BRIDGE_SENS 2 I 0/5V DC BRCM2: On/Off
3+5V O5V DC
5 V DC power output to BRCS2
YC6 1 GND - - Ground
Connected to
the BR con-
veying sen-
sor 2 and BR
cover switch
2 BRIDGE_SENS 1 I 0/5V DC BRCS1: On/Off
3 +5V O 5V DC 5 V DC power output to BRCS1
4 GND - - Ground
5 BRIDGE_OPEN I 0/5V DC BRCUSW: On/Off
6 +5V O 5V DC 5 V DC power output to BRCUSW
7 NC - - Not used
YC7 1 BRIDGE1_B/ O 0/24V DC(pulse) BRCM1 control signal
Connected to
the BR
conveying
motor1,2
2 BRIDGE1_A/ O 0/24V DC(pulse) BRCM1 control signal
3 BRIDGE1_B O 0/24V DC(pulse) BRCM1 control signal
4 BRIDGE1_A O 0/24V DC(pulse) BRCM1 control signal
5 BRIDGE2_B/ O 0/24V DC(pulse) BRCM2 control signal
6 BRIDGE2_A/ O 0/24V DC(pulse) BRCM2 control signal
7 BRIDGE2_B O 0/24V DC(pulse) BRCM2 control signal
8 BRIDGE2_A O 0/24V DC(pulse) BRCM2 control signal
YC8 1 NC - - Not used
Connected to
the BR deca-
ler sensor
2 GND - - Ground
3 DECAL_HP_SENS I 0/5V DC BRDS: On/Off
4 5V O 5V DC 5 V DC power output to BRDS
