3. Press and hold the FB cover actuator (A).
4. The value of FB Cover: should change from 1 to 0 if the sensor is working properly.
5. Press to return to SCANNER TESTS.
ADF cover open sensor test
This test verifies the functionality of the ADF cover closed sensor. To test this sensor. perform the following
steps:
1. ADF Cover Open: 0 appears.
2. Lift the ADF top cover.
3. The value of ADF Cover Open: should change from 0 to 1 if the sensor is working properly.
4. Press to return to SCANNER TESTS.
A
