Parts catalog 7-1
7525-63x
7. Parts catalog
How to use this parts catalog
The following legend is used in the parts catalog:
• Asm-index: Identifies the assembly and the item in the diagram. For example, 3-1 indicates Assembly 3
and item number 1 in the table.
• Part number: Refers to the unique number that identifies the FRU.
• Units/mach: Refers to the number of units actually used in the base machine or product.
• Units/option: Refers to the number of units in a particular option. It does not include the rest of the base
machine.
• Units/FRU: Refers to the number of units packaged together and identified by the part number.
• NS: (Not shown) in the Asm-Index column indicates that the part is procurable but is not pictured in the
illustration.
• PP: (Parts Packet) in the parts description column indicates the part is contained in a parts packet.
• Model information used in the parts catalog:
The Lexmark X548 series MFPs are available in the following models:
Asm-
index
Part
number
Units/mach
- or -
Units/option
Units/
FRU
Description
Machine type/model Product name Description
7525-630 Lexmark X548de Duplex printer, duplex ADF, touch
panel, modem
7525-631 Lexmark X548de Duplex printer, duplex ADF, touch
panel
7525-632 Lexmark X548dte Duplex printer, duplex ADF, touch
panel, hard drive, modem
7525-636 Lexmark X548dte Duplex printer, duplex ADF, touch
panel, hard drive
