2-52 Service Manual
7525-63x
Print quality—residual image
Service tip: Install a new print cartridge, if available, before doing this service check.
Residual image can be caused by the photoconductor, cleaning blade, and other parts
inside the print cartridge.
Step Questions / actions Yes No
1 Check the condition of the imaging unit using
the customer menus (administrative menus):
1. In the Ready prompt, touch .
2. Navigate to Supplies Menu > Imaging
Kit.
Does the display indicate OK?
Go to step 2. Replace the imaging unit or
the photoconductor unit.
See “Developer unit
removal” on page 4-47.
2
Measure the distance from the original image
to the same point on the residual image.
Is the distance 43.9 mm?
Replace the developer
corresponding to the color of
the image. See “Developer
unit removal” on
page 4-47.
Replace the imaging unit or
the photoconductor unit.
See “Developer unit
removal” on page 4-47.
3
Is the distance between the original image
and the residual image 94.2 mm?
Replace the
photoconductor. See
“Developer unit removal”
on page 4-47.
4
Run the Menu Setting Page twice to clear any
debris.
To print a menu settings page:
1. In the Ready prompt, touch .
2. Navigate to Reports > Menu Settings
Page.
Is there still any toner contamination on the
fuser assembly?
Replace the fuser. See
“Fuser assembly
removal” on page 4-32.
Contact your next level of
support.
