5-20 Service Manual

7525-63x

Go Back

Previous

Next

Toner meter card

Connectors

Toner meter card

Connector Pin no. Signal

From JCTM1 connector on the RIP

board

1+5 V_SW

2 Cart_Meter_C_IN

3 Cart_Meter_M_IN

4 Cart_Meter_Y_IN

5 Cart_Meter_K_IN

6 Ground
