Diagnostic information 2-47
7525-63x
Print quality—blank page
7
Replace the HVPS. See “High-voltage power
supply (HVPS) with spring assembly
removal” on page 4-40.
Does this fix the problem?
Problem resolved. Go to step 8.
8
Clean the printhead.
Does this fix the problem?
Problem resolved. Replace the printhead. See
“Printhead removal” on
page 4-61.
Step Questions / actions Yes No
1 Is all the packing material for the imaging unit
in question removed?
Go to step 2. Remove the packing
material.
2
Print a document that requires all four colors
with just a few characters to verify if one
specific color is a problem. For example, print
the Print Quality Test Pages:
1. Enter the Diagnostics Menu (Turn off the
printer, press and hold 3 and 6, turn on the
printer, and release the buttons when the
progress bar appears).
2. Navigate to PRINT TESTS > Print Quality
Pages.
3. Printing Quality Test Pages appears
and the pages print.
Is only one color missing?
Replace the developer unit
for the missing color.
Go to step 3.
3
Replace the imaging unit. See “Developer
unit removal” on page 4-47.
Does this fix the problem?
Problem resolved. Go to step 4.
Step Questions / actions Yes No
