Repair information 4-97

7525-63x

Go Back

AIO link removal

1. Lift the scanner to the up position. Remove the screw (A) securing the AIO link to the AIO toner cover.

2. Return the flatbed to the down position.

3. Remove the screw (B) securing the AIO link to the flatbed unit.
