Locations 5-19

7525-63x

Go Back

Previous

Next

Connectors

LVPS board

Connector Pin no. Signal

CN1 1 +5 V

2 Ground

3 +5 V

4 Ground

5+5 V

6 Ground

7 +24 V

8 Ground

9 +24 V

10 Ground

11 +24 V

12 Ground

13 Relay drive

14 ZC out

15 Heat On

16 NC

CN2 1 AC phase input

2 AC neutral input

CN3 1 AC out

29 AC load phase
