Diagnostic aids 3-31
7525-63x
Scanner Calibration Reset
This procedure should be run after the scanner or ADF has been replaced.
ADF Magnification
This setting enables the adjustment of the ADF’s magnification.
To adjust this setting:
1. Navigate to SCANNER TESTS > ADF Magnification.
2. Touch or to adjust the setting.
3. Touch Submit to save the setting, or touch Back to return to the Diagnostics Menu without saving any
changes.
EXIT DIAGS
This setting appears as a button on the bottom right-hand corner of the display and is always accessible from
the Diagnostics Menu.
Touch this to exit the Diagnostics Menu. The printer performs a POR and starts in normal mode.
