3-6 Service Manual
7525-63x
Diagnostics Menu (Diag Menu)
Note: Tray 2 refers to the 650-sheet tray located in the 650-sheet duo drawer assembly.
Diagnostics Menu structure
When the Diagnostics mode is entered, each Diagnostics main menu item displays on the operator panel. When
a diagnostic test is selected from the main menu, a sub menu displays, and each individual test displays in the
order shown. Any options that are referred to in the menus are displayed when the option is installed.
Available tests
The tests display on the operator panel in the order shown:
REGISTRATION
Printer See “Printer” on page 3-9.
Quick Test See “Quick Test” on page 3-10.
Alignment Menu
Cyan These tests are performed to align the color planes. See “Alignment
Menu” on page 3-11.
Magenta
Yellow
Factory Scanner See “Factory Scanner” on page 3-13.
Factory Manual See “Factory Manual” on page 3-13.
Scanner Calibration
Copy Quick Test See “Copy Quick Test” on page 3-14.
Adjust Calibration Values See “Adjust Calibration Values” on page 3-14.
Reset Flatbed Calibration
Values
See “Reset Flatbed, ADF Front, ADF Back Calibration Values” on
page 3-14.
Reset ADF Front Calibration
Values
Reset ADF Back Calibration
Values
MISC TESTS
Motor Detect See “Motor Detect” on page 3-14.
PRINT TESTS
Tray 1 See “Input source tests” on page 3-15.
Manual Feeder
Print Quality Pgs See “Print Quality Pages” on page 3-16.
HARDWARE TESTS
Panel Test See “Panel Test” on page 3-16.
Button Test See “Button Test” on page 3-17.
DRAM Test See “DRAM Test” on page 3-17.
USB HS Test Mode See “USB HS Test Mode” on page 3-17.
DUPLEX TESTS
Quick Test See “Quick Test (duplex)” on page 3-18.
INPUT TRAY TESTS
Feed Tests See “Feed Tests” on page 3-19.
To Next Page
