Diagnostic aids 3-11
7525-63x
Alignment Menu
Aligns each of the color planes to the black plane. Print the Quick Test under each color, Cyan, Yellow, and
Magenta, and adjust the Top Margin, Left Margin, Right Margin, Skew, and Bow.
Prints the Print Alignment Pages and requires that the best line in each set of lines must be selected.
To get started:
1. Navigate to Alignment Menu.
2. Select a color (Cyan, Yellow, or Magenta).
Note: The yellow alignment page markings are more difficult to see, so you might not want to pick it first.
3. Navigate to Quick Test, to print the Quick Test pages. Quick Test Printing appears, and a page similar
to the following prints:
