Locations 5-5

7525-63x

Go Back

Connectors

Connector Pin no. Signal

JADF1 1 I0A_ADF_C

2 I1A_ADF_C

3 Ground

4 DIRA_ADF_C

5 Ground

6 I0B_ADF_C

7 I1B_ADF_C

8 Ground

9 DIRB_ADF_C

10 Ground

11 V_24_ADF

12 V_24_ADF

13 Ground

14 V_5_ADF

15 PAP_PRES2_2

16 VREF1_ADF_C

17 VREF2_ADF_C

18 PAP_PRES_C

19 ADF_CVR_C

20 FIRST_SCAN_C

21 FB_CVR_C

22 SOL1_EN_2

JBHUSB1 - Rear USB Host Port G1 Ground

1V_BUSB

2 USB_DM2

3 USB_DP1

4 Ground

G2 Ground

JBIN1 1 V_BF

2S_BIN_FB

3 Ground

4V_BIN_4

5FUSER_ES

6 Ground
