Lexmark X548 Series Service Manual

Locations 5-7
7525-63x
Go Back
Previous
Next
JCCD1 - CCD ribbon cable 1 FBR_AFE_SDI
2FBR_AFE_SCK
3 FBR_AFE_SEN
4GND
5FBR_AFE_D(0)
6FBR_AFE_D(1)
7GND
8FBR_AFE_D(2)
9FBR_AFE_D(3)
10 GND
11 FBR_AFE_D(4)
12 FBR_AFE_D(5)
13 GND
14 FBR_AFE_D(6)
15 FBR_AFE_D(7)
16 GND
17 FB_AFE_VSMP_R
18 GND
19 FB_AFE_RSMP_R
20 GND
21 FB_AFE_CLK_R
22 GND
23 FB_CCD_CLAMP_R
24 GND
25 FB_CCD_RESET_R
26 GND
27 FB_CCD_PHASE1_R
28 FB_CCD_PHASE2_R
29 GND
30 FBR_CCD_TRANSFER
31 +5V
32 +5V
33 +14V
34 +14V
35 FB_POWER_SAVER_R
36 FB_LAMP_ON_R
JCFAN1 1 FAN_PWM_PWR
2 Ground
3 FAN_SENSE
Connector Pin no. Signal
