Page #310 background imageLoading...
Page #310 background image
5-10 Service Manual
7525-63x
Go Back
Previous
Next
JHVPS1 1 M_DEV_PWM_OUT
2 K_DEV_PWM_OUT
3 C_DEV_PWM_OUT
4 CMY_CHG_PWM_OUT
5 Y_DEV_PWM_OUT
6 K_CHG_PWM_OUT
7 CMY_SRVO_OUT
8 ITM_TX_PWM_OUT
9 CMY_TX_PWM_OUT
10 ITM_SRVO_OUT
11 K_SRVO_OUT
12 K_TX_PWM_OUT
13 +24V
14 Ground
15 5V_HVPS_REF
16 Ground
JINT1 1 +5V Fused
2 Ground
3 VS_INT
JLVPS1 1 +5V
2 Ground
3+5V
4 Ground
5+5V
6 Ground
7 +24VC
8 Ground
9 +24VC
10 Ground
11 +24VC
12 Ground
13 RELAY_DRIVE
14 ZERO_XING_IN
15 HEAT1_ON
16 GND
Connector Pin no. Signal
