Page #315 background image

Loading...

Page #315 background image

Locations 5-15

7525-63x

Go Back

Previous

Next

JUIC1 1 UI_RESET_NR

2 Ground

3 Y1M_LVDS

4 Y1P_LVDS

5 Y2M_LVDS

6 Y2P_LVDS

7CLK_TX

8CLK_TX+

9 Ground

10 5.0 V dc

11 RXD232_N

12 TXD232_N

13 Y0M_LVDS

14 Y0P_LVDS

15 Ground

16 5.0 V dc

17 5.0 V dc

18 5.0 V dc

JUSB1 Port G1 Ground

1 USB_5V_Sense

2 USB D-

3 USB D+

4 Ground

G2 Ground

JWIN1 1 Ground

2+5V

3TXD1

4+5V

JWT1 1 SENSE

2VREF

3 VAC

4GND

Connector Pin no. Signal
