Parts catalog 7-5

7525-63x

Go Back

Assembly 2: Scanner

Asm-

index

Part

number

Units/

mach

Units/

FRU

Description

2-1 40X5470 1 1 Tray, ADF input

2 40X5478 1 1 Cover, ADF rear duplex

3 40X5479 1 1 Cable, ADF

4 40X5872 1 1 Bin full flag

5 40X8342 1 1 Asm, Redrive

6 40X7529 1 1 Asm, LED flatbed

7 40X5536 1 1 Lever, AIO release

8 40X1569 1 1 Flatbed pivot link

9 40X5487 1 1 Cover, Scanner right

10 40X5488 1 1 Cover, Scanner left

11 40X8092 1 1 Asm, Duplex ADF

12 40X8419 1 1 ADF separator pad replacement CRU

13 40X7545 1 1 ADF separator roll replacement CRU

NS 40X5535 1 1 Flatbed cushion, duplex

NS 40X2252 1 4 Redrive spacer screws
