Parts catalog 7-7

7525-63x

Go Back

Assembly 3: Operator panel

Asm-

index

Part

number

Units/

mach

Units/

FRU

Description

3-1 40X6523 1 1 Cover, Operator panel bezel

2 40X6521 1 1 Display, 7-inch LCD (with ground cable)

3 40X6519 1 1 Cover, Operator panel with keypads, sleep button and light pipe

4 40X6515 1 1 PCBA, UICC

5 40X6516 1 1 Cable, UICC

6 40X5480 1 1 Cable, USB (for thumbdrive)

7 40X6520 1 1 Cover, Operator panel frame

8 40X6517 1 1 Speaker

9 40X6518 1 1 EPROM, PCBA
