Parts catalog 7-13

7525-63x

Go Back

Assembly 6: Electronics 2

Asm-

index

Part

number

Units/

option

Units/

FRU

Description

6-1 40X5429 1 1 ITU paper path thermistor

2 40X5414 2 1 Toner patch sensors, left or right (one in package)

3 40X7046 1 1 Waste toner bottle contact block

4 40X5421 1 1 Imaging unit contact (Pogo pin)

5 40X5423 1 1 Cable packet, used for:

A—AC power in

B—Low-voltage power supply

C—High-voltage power supply

D—Fuser/S1

E—CMY/ K motors

F—Option tray

G—Fuser exit/narrow media/bin full

H—Wire tie (1.0mm)

NS—Tray present cable
