Parts catalog 7-15

7525-63x

Go Back

Assembly 7: Media drawers and trays

Asm-

Index

Part

number

Units/

option

Units/

FRU

Description

7-1 40X6997 1 1 Optional 650-sheet duo drawer (complete)—X548

(includes a 100-sheet MPF)

2 40X5168 2 2 Pick tire replacement CRU

3 40X2285 1 1 650-sheet duo drawer tray assembly—X544n, X544dn, X544dw, X540n,

X543dn (includes a 100-sheet MPF)

Note: Use only with P/N 40X6997 drawer assembly)

4 40X8341 1 1 Optional 550-sheet drawer (complete)—X544n, X544dn, X544dw, X540n,

X543dn

NS 40X2512 1 1 550-sheet MPF latch cover
