Diagnostic information 2-19

7525-63x

Go Back

846.06 Front calibration strip has excessive

dark area.

Front excessive variability for Mono, Red,

Green, or Blue. Go to “CCD service

check” on page 2-60.

846.07 Front magnification exceeds limits Rear excessive variability for Mono, Red,

Green, or Blue. Go to “CCD service

check” on page 2-60.

847 Modem failure The Configuration ID bit that describes the

device’s modem doesn’t match the actual

modem installed in the device.

847.01 Fax storage The amount of flash storage available on

the device is too small.

Note: The NAND Flash partition can shrink

as bit failures cause blocks to be

invalidated.

Go to “Format Fax Storage” on

page 3-37. If the issue is not fixed, replace

the RIP board. Go to “RIP board

removal” on page 4-19.

847.02 Fax storage The devices’ flash partition is invalid or

unavailable. Go to “Format Fax Storage”

on page 3-37. If the issue is not fixed,

replace the RIP board. Go to “RIP board

removal” on page 4-19.

848 Modem/Config ID mismatch A device doesn’t have a modem installed,

even though its Configuration ID indicates

that a modem should be present.

848.01 Modem/Config ID Mismatch A device has a modem installed, but its

Configuration ID indicates that a modem

shouldn’t be present.

849 HD/Config ID mismatch A device doesn’t have a hard drive

installed, even though its Configuration ID

indicates that a hard drive should be

present.

849.01 HD/Config ID mismatch. A device has a hard drive installed, but its

Configuration ID indicates that a hard drive

shouldn’t be present.

9xx.xx service errors

900.xx Service

RIP Software

Unrecoverable RIP software error/

illegal trap.

Go to “900.xx system software error

service check” on page 2-28.

902.xx Service

Engine Software
