Gocator Line Profile Sensors: User Manual
Gocator Device Files • 487
Element Type Description
SpacingIntervalType 32s
Spacing interval type:
0 – Maximum resolution
1 – Balanced
2 – Maximum speed
3 – Custom
SpacingIntervalType.used Bool Whether or not this field is used.
Tracking Section
See Tracking Child Elements on the next page.
Material Section
See Material Child Elements on the next page.
Tracheid
Section See
Tracheid Child Elements on page 491
.
IndependentExposures
Section See
IndependentExposures Child Elements on page 491
Custom Custom Used by specialized sensors.
Element Type Description
X 64f X start(mm).
Y 64f Y start (mm).
Z 64f Z start (mm).
Width 64f X extent (mm).
Length 64f Y extent (mm).
Height 64f Z extent (mm).
ZAngle 64f Z Angle start (degrees).
ZAngle.used Bool Whether or not this property is used.
Region3D Child Elements
Element Type Description
X 32u X start (pixels).
Y 32u Y start (pixels).
Width 32u X extent (pixels).
Height 32u Y extent (pixels).
Window Child Elements
Element Type Description
Grid
Grid
Layout grid information.
MultiplexingBank 32u Multiplexing bank ID
MultiplexingBank.used 32u Whether or not this field can be specified
MultiplexingBank.value 32u Actual value used by system
Layout Child Elements
