Calibration and Adjustment 5-1
5 Calibration and Adjustment
5.1 Overview
After initial installation or if any hardware changes have been made, certain dispensing system
components may need to be calibrated or adjusted. This section covers the following topics:
• Focusing the Camera
• Calibrating the Camera
• Adjusting the Service Station Height
• Calibrating the Scale
• Adjusting the Z-Head Counterbalance Force
• Adjusting the Height Sensor Probe
• Adjusting the Board Sensors
• Initializing the Digital Gauges
• Calibrating the E/P Controllers
• Calibrating the Heaters
• Controlled Process Heat
• Adjusting Manual Airflow for
Impingement Heaters
• Adjusting the Lift Table Speed
• Configuring the Light Beacon
Refer to Section 4 - Operation for the following routine setup and adjustment procedures:
• Installing the Dispensing Valve
• Adjusting the Air Pressure
• Valve Offsets
• Setting the Heaters
 NOTE Refer to the Fluidmove User Guide for information on Fluidmove programming and
fluid setup.
CAUTION! The procedures in this section should only be performed by a trained
service technician.
5.2 Safety First
Operation of your S2-900 Series Dispensing System involves heat, air pressure, electrical power,
mechanical devices, and the use of hazardous materials. It is essential that every person servicing or
operating the dispensing system fully understands all hazards, risks, and safety precautions. Refer to
Section 2 - Safety for important safety information.
5.3 Record Keeping
The type of calibration or adjustment performed should be recorded in maintenance records for the
dispensing system along with names of technicians and other pertinent data.
5.4 Startup/Shutdown
Refer to Section 4 - Operation for details on system and Fluidmove startup/shutdown procedures.
