9-4 Specifications
9.4 System Dimensions
9.4.1 S2-900
NOMINAL PASSLINE HEIGHT (MM)
PASSLINE
RANGE
FOOT
(under machine
clearance)
MIN 913 66
NOMINAL
(SMEMA
1
)
953 106
MAX 965 118
1
SMEMA = 953 mm ± 12.5 mm
Front View (mm)
Side View (mm)
Figure 9-1 S2-900 System Dimensions (1 of 2)
