Nordson Spectrum II Series User Manual

Calibration and Adjustment 5-31
5.17 Adjusting the Lift Table Speed
To adjust the lift table speed:
1. From the Fluidmove Main Menu, select
Configuration > Conveyor Setup > Test I/O.
2. Select the tab labeled Outputs 0-31 (Figure 5-35) and locate the lift output buttons for the
station to be adjusted (Lift_Up_Left, Lift_Up_Ctr, Lift_Up_Right).
3. Toggle the lift output buttons On (1) and Off (0) to lift and lower the table to test the speed
adjustment setting.
Figure 5-35 Conveyor I/O Test Dialog
4. If adjustment is necessary, open the dispensing system hatch.
WARNING! Do not reach into the dispensing chamber until yellow beacon light is displayed
and all system motion has stopped. If the heaters are hot, use extreme caution
when performing this operation.
