Nordson Spectrum II Series User Manual

Parts Replacement 8-3
8.9 Gaining Access to Dispensing System Components
In order to gain access to some areas of the dispensing system, it will be necessary to remove covers,
doors, and access panels. Figure 8-1 shows the location of these features.
WARNING! Make sure that the dispensing system has been completely shut down before
attempting to remove any panel. Remove doors, covers, and panels carefully to
avoid damaging underlying components.
Figure 8-1 Gaining Access to Dispensing System Components
