Nordson Spectrum II Series User Manual

3-8 Installation
3.8 Setting Up the Service Station
The Service Station consists of both the scale station and purge station. The scale is standard on S2-900P
dispensing systems and an option on the S2-900 dispensing systems.
To setup the Service Station:
1. Place the scale lid, cup, pedestal and breeze shield on the scale station (Figure 3-7).
Figure 3-7 Setting up the Scale Station
2. Place the purge cup inside of the purge station (Figure 3-8).
3. Replace the purge station lid.
Figure 3-8 Purge Station
