Nordson Spectrum II Series User Manual

Operation 4-19
4.8.2 Lighting and Color Adjustment
The light intensity and color level can be adjusted to optimize the view of your workpiece. Refer to
Section 5 - Calibration and Adjustment for instructions on focusing and calibrating the camera.
CAUTION! Except for lighting adjustments and lens replacement, all other configuration and
adjustments should only be performed by a trained service technician.
To adjust lighting intensity and color level:
1. Open the hatch, place a workpiece conveyor or tooling plate, and close the hatch.
2. Access the Jog Window using one of the following methods:
• Select
Jog
from the Main Menu.
• Select the
Jog button in the Production Window.
• Press [Ctrl + J] on the keyboard.
3. At the bottom of the Jog Window, click on
Video and when the video display screen
appears, click on
Reticles. See Figure 4-15.
4. In the Reticles Setup Window, use the jog controls to move the dispensing head over the
sample workpiece so that the video display reticles are aligned with a fiducial. See
Figure 4-15.
5. View the fiducial in the video display screen while adjusting the two lighting controls until
you get the highest contrast between the fiducial and substrate or between the part being
dispensed upon and the surrounding area.
6. Adjust the red/green/blue color balance by moving the control slides on the right side of the
window.
 NOTE For more information concerning fiducials and video display contrast, refer to the
Fluidmove User Guide or Online Help.
