Nordson Spectrum II Series User Manual

9-2 Specifications
9.2 Facility Requirements
Table 9-1 Specifications
Facilities Requirements – All Models
System Footprint
Single station (width x depth):
Two stations (width x depth):
Three stations: (width x depth):
600 x 1321 mm (23.6 x 52.0 in.)
850 x 1321 mm (33.5 x 52.0 in.)
1100 x 1321 mm (43.3 x 52.0 in.)
See 9.4 System Dimensions for system drawings.
Clearance Space
Requirement
915 mm
Power (Mains)
Adaptive power supply that accommodates supply voltages between
200-240 VAC, 47-63 Hz single phase.
Short Circuit Current Rating
(SCCR)
10 KA
Facility Circuit Requirement
1
S2-900 w/ 10A Power Supply
S2-900P or S2-900 w/ 30A Supply
10A
30A
(NEMA L6-30 Outlet Plug Provided)
Amperage (typical
Single lane Dual lane Per Heated Tool Total Amperage
4.6A 5.2A 4.7A
Base system +
heated tooling
Installation
(Over-Voltage Category)
Category II
Air Supply
2
Two air supplies: one with 3 CFM @ 100 psi for contact tooling, a second one
with 1 CFM @ 100 psi for the rest of the system (100 psi = 689 kPa, 6.8 atm).
Pneumatic Fittings 9084-23-14, ¼-inch quick disconnect fittings
Air Consumption Application-dependent
House Vacuum (S2-9XXC) ~1 CFM @ 22 inHg max during purge routine
Energy Consumption
~6.0KWh max (with heat)
~0.4KWh max (without heat)
System Noise
<70 dBA, 76 db peak @ 1 M (does not include valve operation noise)
Environmental Conditions
(Operation and Storage)
Shipping: 5-55 °C, 5-90% RH
Operating: 18-28
°
C, 5-90% RH
Ventilation
Downdraft or updraft
Vent port diameter: 147.6 mm (5.8 in.)
NOTE: Contact the factory regarding impingement heat applications:
100 cfm from the exhaust port may be required.
System Weight
3
Single station:
Two stations:
Three stations:
377 kg. (831 lbs.)
399 kg. (880 lbs.)
422 kg. (930 lbs.)
Crate Dimensions
1930 x 1321 x 1981 mm (76.0 x 52.0 x 78.0 in.)
Crated Weight
590 kg (1300 lbs)
Standards Compliance
SMEMA, CE, SEMI-S2, SEMI-S8, NFPA 79
1
10A Power Manager may use either 120VAC or 240VAC input power supply
2
S2-900/900P system when configured with regular impingement tools: requires one air supply with 9 CFM @ 100 psi for
impingement air and a second air supply with 1 CFM @ 100 psi for the rest of the system. S2-900/900P system when configured
with the high-flow impingement option: requires one air supply with 14 CFM @ 100 psi for impingement air and a second air supply
with 1 CFM @ 100 psi for the rest of the system.
3
Basic weight without options; actual system weight will depend on the specific configuration.
