Nordson Spectrum II Series User Manual

Operation 4-17
4.7.3 Using the Keyboard
To jog the dispensing head and conveyor using keyboard commands:
1. Press [Ctrl + J] to open the Fluidmove Jog Window.
2. Using the mouse, click on the
Dispenser radio button to activate the dispensing head jog
controls, the
Conveyor 1 radio button to activate the Conveyor 1 jog controls or the
Conveyor 2 radio button to activate the Conveyor 2 jog controls.
3. Press the appropriate keys shown in Table 4-4 to jog the selected device (conveyor or
dispensing head).
Table 4-4 Jog Control Keyboard Commands
Speed of
Movement
Command
(1)
Dispensing Head
Response
Conveyor
Response
Ctrl + H
Moves to front left corner of
dispensing chamber.
Rear rail moves all the way
to the back of dispensing
chamber.
Slow
(2)
Ctrl + ← Moves left Belts move left
Ctrl + ↑
Moves backward Rear rail moves to back
Ctrl + →
Moves right Belts move right
Ctrl +
↓
Moves to front Rear rail moves to front
Ctrl + Z + ↓
Moves downward N/A
Ctrl + Z + ↑
Moves upward N/A
Fast
(3)
Ctrl + Shift + ← Moves left Belts move left
Ctrl + Shift + ↑
Moves backward Rear rail moves to back
Ctrl + Shift +
→
Moves right Belts move right
Ctrl + Shift + ↓
Moves forward Rear rail moves to front
Ctrl + Shift + Z + ↓
Moves downward N/A
Ctrl + Shift + Z + ↑
Moves upward N/A
Note: (1) Simultaneously press the keys shown.
(2) Slow is the same as clicking on a single arrow in the Jog Control window.
(3) Fast has the same effect as clicking on a double arrow in the Jog Control window.
 NOTE(s) The selected jog device is indicated in the bottom right-hand corner of all major
Fluidmove windows.
Keyboard commands are the same for both single and dual conveyor systems.
