Maintenance 6-5
Item
Description
1 Purge Boot
2 Purge Station Cover
3
Purge Station Cup
4 Purge Station
5 Scale Station Cover
6 Scale Station Cup
7 Scale Station
Figure 6-1 Replacing the Purge and Scale Station Cups
5
6
4
3
1
o7
o2
