Nordson Spectrum II Series User Manual

Appendix B - Block Diagrams B-3
Table B-2 30A Power Manager Connections
Item
Name
Description
1
AC1-AC2 Breaker Reset
Resets the AC1-AC2 circuit breakers.
2 AC1 Unswitched Supplies AC power to the computer.
3
AC2 Unswitched
Spare unswitched DC outlet.
4
AC3 EMO Switched
Supplies AC power to the servo power supply.
5 AC4 EMO Switched Spare
6 AC5 EMO Switched Spare
7
AC6 EMO Switched
Spare
8 AC7 EMO Switched Supplies power to the conveyor module CV1.
9
AC8 EMO Switched
Supplies power to the optional conveyor module CV2.
10 AC7 Breaker Reset Resets the AC7 circuit breaker.
11 AC8 Breaker Reset Resets the AC8 circuit breaker.
12
AC3-AC6 Breaker Reset
Resets the AC3-AC6 circuit breakers.
13 Power Controls Connects to the Start, Stop, and EMO power controls.
14 DC Power Status Provides machine power status to the main PWA electronics.
15 DC Outlet A Provides power to the scale.
16 +24 VDC Switched Supplies DC power to the terminal block located on the lower e-pan.
17 +24 VDC Switched Spare switched DC outlet.
18 Rear EMO Connects to the rear EMO switch.
19
Protective Earth
Connection
Connects the machine’s chassis to the power manager’s protective
earth.
20 Time Delay Config
Access panel for configuration switches that change between "Time
Delay" and "Instant On" power up characteristic.
21
Vent Air Switch
Connects to the vent air switch (bypassed in default configuration).
