Appendix B - Block Diagrams B-5
Table B-3 Conveyor/Heater Module Connections
Item Name Description
1 Heater 1-4 Connections Heater Connections.
2 Protective Earth Connection
Connects the machine’s chassis to the conveyor/heater module’s
protective earth.
3 Flow 1-4 Connections Impingement Flowmeter connections.
4 Panel Mounted Fuses (8) Replaceable 6.3A, 250V, slow fuses.
5 AC Power Connects AC power to the conveyor controller.
6 SMEMA Downstream Connects to the machine’s external downstream SMEMA port.
7 SMEMA Upstream Connects to the machine’s external upstream SMEMA port.
8 Interlock Connector Connects to the machine's safety interlock system.
9 Home Sensor Connects to the conveyor’s width home sensor.
10 Sensors A Connects to board sensors mounted on the conveyor rails.
11 Sensors B Spare
12 Solenoids
Controls solenoids related to conveyor functions
(stop, lift, vacuum).
13 CAN-2 CAN serial communications out of the module.
14 CAN-1 CAN serial communications in to the module.
15 Belt Front Controls the front belt stepper motor.
16 Belt Rear Controls the rear belt stepper motor.
17 Width Motor Controls the rail width stepper motor.
