Proceed as follows:
Remove the upper smoothing
roller:
■
Push the bearing bolts up-
wards on the left-hand side
(in paper path direction).
■
Push the bearing bolts up-
wards on the right-hand side
(in paper path direction).
■
Carefully remove the
smoothing roller from the
guide rails
9.
If the lower smoothing roller is to be replaced: continue with step 11.
If only the upper smoothing roller is to be replaced: More information in sec-
tion ‘Installing smoothing rollers’ on page 461.
10.
Cut the paper web off at a clean
right angle.
11.
At the paper output:
Pull out the cut-off paper web:
12.
Chapter 9 - Replacing Expendables458
Removing the smoothing rollers
