4 Patient Alarms and INOPs
102
Telemetry INOPs
ProtocolWatch INOPs
Calculated Values INOPs
Text Upload Failed
INOP tone
Incoming text from the IntelliBridge modules exceeds the maximum limit. Try unplugging one of the
IntelliBridge modules. If the INOP occurs repeatedly contact your service personnel; a software
upgrade may be necessary.
INOP Message, Indication What to do
INOP Message, Indication What to do
Check ECG Settings
INOP tone
Synchronization of ECG settings between the monitor and Information Center has failed. Check that
the ECG settings in use are appropriate.
!!Check ECG Source Both the telemetry device and the monitor have valid ECG signals
Chk SpO₂T Settings
INOP tone
Synchronization of SpO
2
T settings between the monitor and Information Center has failed. Check
that the SpO
2
T settings in use are appropriate.
Invalid Leadset The leadset plugged in cannot be used with the telemetry device.
Leadset Unplugged The leadset has been unplugged from the telemetry device.
No ECG Source A telemetry device is paired with the monitor but the Information Center is not detecting a valid ECG
signal from either of them.
!! Repl. Tele Batt
!!!Repl. Tele Batt
Severe yellow/red INOP tone
During this INOP, alarms cannot
be paused or switched off.
The battery in the telemetry device is almost empty and must be replaced.
Tele Battery Low The battery in the Telemetry device is low and must be replaced soon.
!!Tele Disconnect
!!!Tele Disconnect
Severe yellow/red INOP tone
Telemetry transceiver was disconnected or short range radio link was lost.
For cable connections; check Telemetry interface, cable connection and setup.
For short range radio connections: if the telemetry transceiver has not moved out-of-range, check for
interference sources close to the monitor (bluetooth devices, DECT phones, cellular phones,
microwaves, etc.). If this INOP persists, ask your service personnel to survey the interference sources.
!! Tele INOP
!!! Tele INOP
Severe yellow/red INOP tone
Check for further details at the Information Center or in the Telemetry Data window on the monitor.
Tele Sync Unsupp.
INOP tone
The MMS in use does not support synchronization of ECG and SpO
2
settings between the monitor
and central station after a telemetry device has been paired. Use an MMS with revision E.0 or above.
INOP Message, Indication What to do
PW: Check Settings Contact your service personnel. Settings could not be loaded or interpreted correctly.
PW: In Conflict There is a patient information mismatch which has not yet been resolved (>15 minutes).
PW:Action Required The protocol currently running requires a user response. Check which pop-up window is displayed and
provide the appropriate response.
INOP Message, Indication What to do
ΔSpO₂ Chk Sources
Numeric is replaced by -?-
Not all measurements or values required to perform the calculation are available. Check measurement
sources.
