13 Monitoring Cardiac Output
226
Hemodynamic Parameters
This table illustrates the hemodynamic parameters available with each method, whether they are
measured continuously, and whether they can be shown on the monitor's main screen or in the
Hemodynamic Calculations window.
* currently not available in the U.S.A. and territories relying on FDA market clearance.
NOTE
EVLWI is calculated using Ideal Body Weight (IBW). ITBVI and GEDVI are calculated using Ideal
Body Surface Area (IBSA). IBW and IBSA are based on the patient category, gender and height that
you have entered for the patient.
Using the C.O. Procedure Window
The procedure window displays up to six trials (measurement curves) with the trial number and the
C.O. value under the thermodilution curve. When you open the window, a line of pop-up keys
automatically appears to let you carry out C.O.-related tasks. This example shows the procedure
window for the transpulmonary (PiCCO) Method. The window may be configured to look slightly
different on your monitor.
Measured and Calculated Hemodynamic
Parameters and Indexes
PiCCO Method (Transpulmonary
Thermodilution)
Right Heart Thermodilution
Continuous?
Main
Screen
HemoCalc
Window
Continuous?
Main
Screen
HemoCalc
Window
Blood Temperature (Tblood) Yes Yes No Yes Yes No
C.O./C.I.: Cardiac Output No Yes Yes No Yes Yes
CCO/CCI: Continuous Cardiac Output Yes Yes Yes (in the
C.O. field)
Not available
SVR/SVRI: Systemic Vascular Resistance Both Yes Yes No No Yes
SV/SI: Stroke Volume/SV Index Both Yes Yes No No Yes
SVV: Stroke Volume Variation Yes Yes Yes Not available
*dPmax: Left Ventricular Contractility Index Yes Yes Yes Not available
CFI: Cardiac Function Index No Yes Yes Not available
PPV: Pulse Pressure Variation Yes Yes Yes Not available
ITBV/ITBVI: Intrathoracic Blood Volume No Yes Yes Not available
EVLW/EVLWI: Extravascular Lung Water No Yes Yes Not available
GEDV/GEDVI: Global End-Diastolic Volume No Yes Yes Not available
*PVPI: Pulmonary Vascular Permeability Index No Yes Yes Not available
*GEF: Global Ejection Fraction No Yes Yes Not available
*RLShnt: Right-Left-Shunt Fraction No No No Not available
PVR/PVRI: Pulmonary Vascular Resistance Not available No No Yes
LCW/LCWI: Left Cardiac Work No No Yes No No Yes
RCW/RCWI: Right Cardiac Work Not available No No Yes
RVSW/RVSWI: Right Ventricular Stroke Work Not available No No Yes
