4 Patient Alarms and INOPs
94
SO2 INOPs
CO₂NoTransducer
from mainstream CO
2
(except
M3014A)
Numeric is replaced by -?-
INOP tone
There is no CO
2
transducer connected. If you replace the transducer, the new transducer must be
calibrated. If you silence this INOP the CO
2
measurement will be switched off.
CO₂Zero Running Wait until zero calibration is finished.
CO₂ZeroRequired
Numeric is replaced by -?-
INOP tone
Perform zero calibration for the CO
2
sensor. If the INOP persists, contact your service personnel.
IPI Check Pat. Age For Adult patients: a date of birth has been entered that results in a calculated patient age of less than
12 years. Enter correct date of birth or, if patient is pediatric, correct patient category.
For pediatric patients: either no date of birth has been entered (it is required for calculation of IPI for
pediatric patients) or the calculated age is below 1 year or above 12 years. Check that correct date of
birth is entered.
IPI Check Sources The IPI numeric cannot be provided as one or more of the measurement sources required for IPI is
not available. Check availability of etCO
2
, awRR, SpO
2
, and pulse rate.
IPI Neo Patient ? Check patient category. The IPI numeric is not available for neonatal patients.
INOP Message, Indication What to do
INOP Message, Indication What to do
<SO₂ Label> Cal Failed
Numeric is replaced by -?-
INOP tone
The calibration failed. Check the catheter-to-Optical-Module connection. Manually restart the
calibration. Try another catheter and Optical Module. If the catheter is already inserted, perform an in-
vivo calibration.
<SO₂ Label>Cal Required
Numeric is replaced by -?-
INOP tone
There is no valid calibration data in the Optical Module. Perform either a pre-insertion or an in-vivo
calibration.
<SO₂ Label> Cal. Mode
Numeric is replaced by -?-
INOP tone
Pre-insertion calibration is complete, but the catheter tip is still inside the optical reference. The
catheter is now ready for insertion.
<SO₂ Label> Cannot Meas
Numeric is replaced by -?-
INOP tone
The signal is out of the normal range, and no oxygen saturation can be derived. Perform an in-vivo
calibration. If the INOP persists, try another Optical Module and catheter.
<SO₂ Label>Config Error
Numeric is replaced by -?-
INOP tone
The Optical Module has been configured to SaO
2
Mode. Use Change to Venous in the setup
menu to reconfigure to venous saturation mode.
<SO₂ Label> Conn
OptMod
Numeric is replaced by -?-
INOP tone
The Optical Module was disconnected during data storage. Reconnect the Optical Module for at least
20 seconds.
<SO₂ Label> Equip Malf
Numeric is replaced by -?-
INOP tone
The SO
2
/SvO
2
Module or Optical Module is faulty. Unplug and replug the Optical Module and SO
2
/
SvO
2
module. Exchange the modules. If the INOP persists, contact your service personnel.
<SO₂ Label> Incompat.
INOP tone
The SO
2
Module or Optical Module is not supported. Contact your service personnel.
<SO₂ Label> In-Vivo Cal The in-vivo calibration is not yet complete. Lab values must be stored to the Optical Module to
complete the calibration. Either continue with the next steps of the current calibration or recall the
previous calibration.
