Recorder Accessories

Battery Accessories

Description Part No.

For the M1116B recorder:

10 rolls of paper 40477A

80 rolls of paper 40477B

For the integrated recorder (MX400/MX450) and the M1116C recorder

10 rolls of paper M4816A

80 rolls of paper M4817A

Description Part No.

Lithium Ion Smart Battery 1Ah (internal battery for X2) M4607A

Lithium Ion Smart Battery 6Ah (for MX400/MX450/MX500/MX550) M4605A

Battery Charger and Conditioner (requires size adapter 451261017451 to charge M4607A

battery)

865432

Size adapter for M4607A battery 451261017451
