22 Using a Telemetry Device and a Monitor (PIIC only)
309
Unpairing the Monitor and Telemetry Device
If the patient will no longer be monitored with the telemetry device, or only with the telemetry device
and no longer with the monitor, you need to end the device pairing. After unpairing, the Information
Center will receive data exclusively from the monitor or from the telemetry device:
• select the
Unpair To Mon. SmartKey to end pairing and have the Information Center receive the
measurement data from the monitor
• select the
Unpair To Tele SmartKey to end pairing and have the Information Center receive the
measurement data from the telemetry device
or
use the Unpair function at the Information Center.
NOTE
The SmartKeys and pop-up keys for unpairing appear only on the monitor which is directly involved
in pairing.
Use Models With Telemetry
The standard use model combining a monitor and a telemetry device involves pairing the two devices
so that the data measured by the telemetry device appears on the monitor screen - and at the
Information Center in the same patient sector as the monitor data. The following variations are
possible:
1 The monitor is paired with a telemetry transceiver - indirect connection
– telemetry data appear on the monitor
2 An X2 is declared as a telemetry device and paired with an MX400/MX450, MX500/MX550, or
MX600/700/800 monitor - direct or indirect connection
– X2 measurement data appear on the monitor it is paired with
– a telemetry transceiver cannot be used with the X2
3 A telemetry transceiver directly connected via SRR to an X2, that is connected (via Companion
Mode) to an MX400/450, MX500/550, or MX600/700/800 monitor - direct connection
– telemetry data appear on the host monitor
– telemetry transceiver is paired with the host monitor but is assigned to the X2
– the X2 must have no equipment label
The different variations require different configuration settings; refer to the Configuration Guide for
details.
