6 ECG, Arrhythmia, ST and QT Monitoring
148
Printing the 12-Lead ECG
Print a dedicated 12-Lead ECG report by selecting the Print Report pop-up key.
When you are working with an Information Center iX that provides 12-Lead analysis, the report
contains the 12-Lead analysis results as well as measurement values (e.g. ST values, QT values, HR)
which are also downloaded from the Information Center iX. If you work with an Information Center
which does not provide any 12-Lead analysis results, the report only contains the measurement values.
In this case, however, the values are based on the real-time measurements made at the bedside.
Consequently, the measurement values in the report might differ in the two cases, due to the slightly
different algorithm approaches of patient monitor (real-time measurement) and Information Center iX
(diagnostic interpretation of 12-Lead capture).
Downloading Analysis Results (PIIC iX only)
Download analysis results from the IntelliVue Information Center by selecting Show Analysis. Return
to the previous screen by selecting
Hide Analysis.
Reviewing Previewed or Stored 12-Lead Captures
To view 12-Lead captures previewed or stored on the monitor or 12-Lead captures stored at the
IntelliVue Information Center (PIIC iX only), select
Review 12 Lead. You can then select from a list
of 12-Lead captures available for the current patient.
The 12-Lead captures in the list may be marked with a symbol, for example an open or closed padlock
to indicate unlocked or locked status or a * to indicate preview status.
Information Center Remote Export (PIIC iX only)
Use the Export key to remotely start the 12-Lead export functionality of the IntelliVue Information
Center.
Information Center Remote Lock/Unlock (PIIC iX only)
Use the Lock key to remotely lock the 12-Lead capture at the IntelliVue Information Center. If it is
already locked, the
Unlock key will be displayed.
Capture 12-Lead Pop-up Keys
Here is a summary of all the pop-up keys available during the 12-Lead ECG procedure:
Pop-up Keys Selecting this pop-up key lets you
Admit Patient enter the age and gender for the patient, to allow analysis of the 12-Lead
ECG.
Change View switch between the single column and two-column display of the realtime
wave data.
Capture Waves capture the current ECG waves and open the preview window.
Show Waves return to the realtime 12-Lead ECG view.
Setup 12 Lead choose settings for filter, gain, display layout, etc.
Enter OrderNo. enter an order number that is stored with the capture and displayed in the
title bar of the pop-up keys.
Print Report print a 12-Lead report.
