40 Specifications

452

Dual medical information bus (MIB) RS232 Interface card

(color-coded yellow)

IntelliBridge EC10 interface board (color-coded dark gray)

Advanced system interface:

Single medical information bus (MIB) RS232 Interface card

(color-coded yellow)

Nurse call

Additional USB slots

Optional Interface Description
