40 Specifications
471
IntelliVue Instrument
Telemetry Wireless Network
(USA only)
Type Internal WMTS Adapter
Technology compatible with Philips IntelliVue Telemetry System (ITS),
cellular infrastructure
Frequency Band WMTS, 1395-1400 MHz and 1427-1432 MHz
IntelliVue Instrument
Telemetry Wireless Network
(except USA)
Type Internal ISM Adapter
Technology compatible with Philips IntelliVue Telemetry System (ITS),
cellular infrastructure
Frequency Band 2.4 GHz ISM
IntelliVue 802.11 Bedside
Adapter (Wireless Network
Adapter)
Type Internal Wireless Adapter
Technology IEEE 802.11a/b/g
Frequency Band 2.4 GHz and 5 GHz Band
Modulation technique DSSS (CCK, DQPSK, DBPSK), OFDM (BPSK, QPSK, 16-
QAM, 64-QAM)
Effective radiated power (max.) MX400-MX550: 16 dBm (35 mW)
MX600-MX800: 17 dBm (50 mW)
Short Range Radio Interface Type Internal SRR interface
Technology IEEE 802.15.4
Frequency band 2.4 GHz ISM (2.400 - 2.483 GHz)
Modulation technique DSSS (O -QPSK)
Effective radiated power max. 0 dBm (1 mW)
Measurement Link (MSL)
MX600/700/800
Connectors ODU out (Proprietary)
Voltage 56 V ±10 %
Power 45 W
Power Sync. 5 V CMOS Level; 78.125 kHz (typ.)
LAN signals IEEE 802.3 10-Base-T compliant
Serial signals RS-422 compliant
Measurement Link (MSL)
MX400/450/500/550
Connectors ODU out (Proprietary)
Voltage 48 V ±10 %
Power 12 W
Power Sync. 5 V CMOS Level; 78.125 kHz (typ.)
LAN signals IEEE 802.3 10-Base-T compliant
Serial signals RS-422 compliant
Video Interface (standard) Connector DVI (digital and analog, single link)
Digital video signals single link TMDS
Analog video signals 0.7 Vpp@75 Ω
HSYNC/VSYNC signals TTL
DDC signals none (except for MX400/450/500/550)
DDC power 5 V +/-5% @0-55 mA
MX400/450/500/550/600/700/800
