Section 26: XLII SLIDE-OUT
PA1553
47
SID
#
FAULT MESSAGE TEXT PROBABLE CAUSE CORRECTIVE ACTION
Shorted High Wire between parking brake
switch and CECM is shorted to
12v or 24v.
Fix wiring harness.
Shorted High Wiring harness shorted to 12v or
24v
Fix wiring harness 9 SldO Mot SpeedA Ctr
Current Above
normal
Security pin or object stop the
movement of a slide-out
Check / fix security pin
functionality.
Check / remove any object
around the slide-out.
Shorted High Wiring harness shorted to 12v or
24v
Fix wiring harness 10 SldO Mot SpeedB Ctr
Current Above
normal
Security pin or object stop the
movement of a slide-out
Check / fix security pin
functionality.
Check / remove any object
around the slide-out.
Shorted High LED or wiring harness shorted to
12v or 24v
Fix LED or wiring harness
Shorted Low Led or wiring harness shorted to
ground
Fix LED or wiring harness
Open Circuit LED is broken.
Bad connection on handheld
control.
Wiring harness is cut.
Check / fix remote LED or
connection
Check /fix wiring harness
11 SldO Remote Led
Current Above
normal
Led or wiring harness shorted to
12v or 24v
Fix Led or wiring harness
Shorted High Solenoid or wiring harness
shorted to 12v or 24v
Fix solenoid or wiring
harness
Shorted Low Solenoid or wiring harness
shorted to ground
Fix solenoid or wiring
harness
Open Circuit Solenoid is broken or open.
Bad connection on solenoid or
bloc valve.
Wiring harness is cut.
Check / fix solenoid or
connection
Check /fix wiring harness
12 SldO Seal Inf Sol
Current Above
normal
Solenoid or wiring harness
shorted to 12v or 24v
Fix solenoid or wiring
harness
Shorted High Solenoid or wiring harness
shorted to 12v or 24v
Fix solenoid or wiring
harness
Shorted Low Solenoid or wiring harness
shorted to ground
Fix solenoid or wiring
harness
Open Circuit Solenoid is broken or open.
Bad connection on solenoid or
bloc valve.
Wiring harness is cut.
Check / fix solenoid or
connection.
Check /fix wiring harness
13 SldO Seal Def Sol
Current Above
normal
Solenoid or wiring harness
shorted to 12v or 24v
Fix solenoid or wiring
harness
Shorted High Solenoid or wiring harness
shorted to 12v or 24v
Fix solenoid or wiring
harness
Shorted Low Solenoid or wiring harness
Shorted to ground
Fix solenoid or wiring
harness
Open Circuit Solenoid is broken or open.
Bad connection on solenoid or
bloc valve.
Wiring harness is cut.
Check / fix solenoid or
connection
Check / fix wiring harness
14 SldO Vacc Gen Sol
Current Above
normal
Solenoid or wiring harness
shorted to 12v or 24v
Fix Solenoid or wiring
harness
15 SldO Mot Neg Rly Shorted High Relay coil or wiring harness
shorted to 12v or 24v
Fix relay coil or wiring
harness
Shorted Low Relay coil or wiring harness
shorted to ground
Fix relay coil or wiring
harness
To Next Page
