PREVOST LE MIRAGE XLII BUS SHELLS User Manual

Section 26: XLII SLIDE-OUT
PA1553
48
SID
#
FAULT MESSAGE TEXT PROBABLE CAUSE CORRECTIVE ACTION
Open Circuit Relay coil is broken or open.
Bad connection on relay.
Wiring harness is cut.
Check / fix relay coil or
connection
Check / fix wiring harness
Current Above
normal
Relay coil or wiring harness
shorted to 12v or 24v
Fix relay coil or wiring
harness
Shorted High Relay coil or wiring harness
shorted to 12v or 24v
Fix relay coil or wiring
harness
Shorted Low Relay coil or wiring harness
shorted to ground
Fix relay coil or wiring
harness
Open Circuit Relay coil is broken or open.
Bad connection on relay.
Wiring harness is cut.
Check / fix relay coil or
connection
Check / fix wiring harness
16 SldO Mot Pos Rly
Current Above
normal
Relay coil or wiring harness
shorted to 12v or 24v
Fix relay coil or wiring
harness
17 SldO Open Sw Shorted High Switch or wiring harness shorted
to 12v or 24v
Fix switch or wiring harness
18 SldO Close Sw Shorted High Switch or wiring harness shorted
to 12v or 24v
Fix switch or wiring harness
19 SldO Limit In Se Shorted High Sensor or wiring harness shorted
to 12v or 24v
Fix sensor or wiring harness
20 SldO Limit Out Se Shorted High Sensor or wiring harness shorted
to 12v or 24v
Fix sensor or wiring harness
21 SldO Secu Pin Sol Shorted High Solenoid or wiring harness
shorted to 12v or 24v
Fix solenoid or wiring
harness
Shorted Low Solenoid or wiring Harness
shorted to ground
Fix solenoid or wiring
harness
Open Circuit Solenoid is broken or open.
Bad connection on solenoid or
bloc valve.
Wiring harness is cut.
Check / fix solenoid or
connection.
Check / fix wiring harness
Current Above
normal
Solenoid or wiring harness
shorted to 12v or 24v
Fix solenoid or wiring
harness
22 SldO Limit In Out Mechanical Or
Electrical Fault
In Limit and Out Limit are seen at
the same time.
In Limit or Out Limit problem.
Check / replace in limit or out
limit sensors
Fix wiring harness.
23 Limit Sensor 5 V supply Shorted Low 5v IO-B output is less than 2v.
Wiring harness is open or shorted
to ground.
Check 5v output on IO-B /
replace IO-B module.
Fix wiring harness.
