Section 01: ENGINE
PA1553
14
DDEC V Code PID SID FMI DESCRIPTION
62 -- 56 7
Aux. Output #8 Mechanical System Not Responding
Properly - Pin V-53
62 -- 257 3 Aux. Output #9 Open Circuit – Pin V-54
62 -- 257 4 Aux. Output #9 Short to Gnd – Pin V-54
62 -- 257 7 Aux. Output #9 Mechanical System Failure – Pin V-54
62 -- 258 3 Aux. Output #10 Open Circuit – Pin V-55
62 -- 258 4 Aux. Output #10 Short to Gnd – Pin V-55
62 -- 258 7 Aux. Output #10 Mechanical System Failure – Pin V-55
62 -- 259 3 Aux. Output #11 Open Circuit – Pin E-13
62 -- 259 4 Aux. Output #11 Short to Gnd – Pin E-13
62 -- 259 7 Aux. Output #11 Mechanical System Failure – Pin E-13
63 -- 57 0 PWM #1 Above Normal Range, Pin V-53
63 -- 57 1 PWM #1 Below Normal Range, Pin V-53
63 -- 57 3 PWM #1 Short to Battery (+), Pin V-53
63 -- 57 4 PWM #1 Open Circuit, Pin V-53
63 -- 58 0 PWM #2 Above Normal Range, Pin V-46
63 -- 58 1 PWM #2 Below Normal Range, Pin V-46
63 -- 58 3 PWM #2 Short to Battery (+), Pin V-46
63 -- 58 4 PWM #2 Open Circuit, Pin V-46
63 -- 59 0 PWM #3 Above Normal Range, Pin E-3
63 -- 59 1 PWM #3 Below Normal Range, Pin E-3
63 -- 59 3 PWM #3 Short to Battery (+), Pin E-3
63 -- 59 4 PWM #3 Open Circuit, Pin E-3
63 -- 60 0 PWM #4 Above Normal Range, Pin E-4
63 -- 60 1 PWM #4 Below Normal Range, Pin E-4
63 -- 60 3 PWM #4 Short to Battery (+), Pin E-4
63 -- 60 4 PWM #4 Open Circuit, Pin E-4
63 -- 267 0 PWM #5 Above Normal Range - Pin E-8
63 -- 267 1 PWM #5 Below Normal Range - Pin E-8
63 -- 267 3 PWM #5 Short to Battery (+) - Pin E-8
63 -- 267 4 PWM #5 Open Circuit - Pin E-8
63 -- 267 7 PWM #5 Mechanical System Failed - Pin E-8
63 -- 268 0 PWM #6 Above Normal Range - Pin E-11
63 -- 268 1 PWM #6 Below Normal Range - Pin E-11
63 -- 268 3 PWM #6 Short to Battery (+) - Pin E-11
63 -- 268 4 PWM #6 Open Circuit - Pin E-11
63 -- 268 7 PWM #6 Mechanical System Failed - Pin E-11
