1.29 JAKE BRAKE
1. Solenoid Valve 12. Inner Control Valve Spring
2. Upper Seal 13. Washer
3. Center Seal 14. Retaining Ring
4. Lower Seal
15.J-Lash
®
Screw
5. Master Piston 16. Locknut
6. Master Piston Pushrod 17. Slave Piston
7. Master Piston Spring 18. Slave Piston Bridge
8. Washer 19. Outer Slave Piston Spring
9. Retaining Ring 20. Inner Slave Piston Spring
10. Control Valve 21. Slave Piston Spring Seat
11. Outer Control Valve Spring 22. Shoulder Bolt
Figure 1-416a Typical Model 790 Jake Brake Assembly
NOTICE:
This application and adjustment information must be strictly
followed. Failure to follow these instructions may result in
serious engine or engine brake damage.
All information subject to change without notice.
1-528 From Bulletin 16-60-99 6SE483 9901 Copyright © 1999 DETROIT DIESEL CORPORATION
