1.29 JAKE BRAKE
4. Install the slave piston assembly torsion spring with the ends over the bridge.
See Figure 1-434.
Figure 1-434 Installing the Slave Piston Assembly Torsion Spring
5. Install the screw over the center part of the spring.
NOTICE:
While tightening the screw on the torsion spring, push the
spring toward the slave piston assembly. Failure to do so may
result in contact between the intake valve adjusting screw and
torsion spring. Serious engine damage may result.
6. Torque the screw to 20 N·m (15 lb·ft.).
7. Torque the slave piston leveling screw locknut to 47 N·m (35 lb·ft.).
All information subject to change without notice.
1-550 From Bulletin 16-60-99 6SE483 9901 Copyright © 1999 DETROIT DIESEL CORPORATION
