Chapter 12 Installing, Removing, and Replacing
Cabling the Library
Scalar i500 User’s Guide 295
Figure 37 HP LTO-5 Dual Port
Fibre Channel Tape Drive
1 Ethernet port — Use for Ethernet
connectivity in conjunction with
FIPS.
2 Fibre Channel port 1 — Default
data port. If you are only using one
port, use this port.
3 Fibre Channel port 2 — Default
failover port (for use with data
path failover).
