Chapter 1 Description
Understanding the Location Coordinates
Scalar i500 User’s Guide 33
following digits: [Module],[Column],[Slot]. Figure 11 shows how a
library with a control module and an expansion is numbered.
Figure 11 Library Location
Coordinates
Note: The library location coordinates are different from the logical
element addressing; see Understanding Logical Element
Addressing on page 35 for more information.)
